Secure Elite 448 CL 0.5s Multi Functional Meter
- 41%

Secure Elite 448 CL 0.5s Multi Functional Meter

(2 customer reviews) 0 sold

Original price was: ₹11,016.00.Current price is: ₹6,550.00.

Indobazzar : Secure Elite 448 CL 0.5s Multi Functional Meter

Secure Elite 448 CL 0.5s is a multi-line three-phase digital panel meter for accurate and reliable measurement of electrical parameters (voltage, current, power, frequency, etc.) for industrial and commercial applications. It has a large multi-line backlit LCD display which enables four parameters to be displayed at the same time. Modbus communication capability allows easy integration with energy monitoring systems. Expansion modules can be fitted for enhanced system integration (pulse inputs/outputs or analogue output and ethernet).

Out of stock

MODEL NUMBER ELITE 440 448
HSN 90283010
BRAND NAME Secure
DISPLAY TECHNOLOGY LCD
ACCURACY CLASS 0.5
TECHNICAL SPECIFICATION VAF, PF, Active Power, Active/apparent forwarded
energy, Load On/Off, THD, RPM, Modbus on RS 485
ARRPVED STATE All State Approved
ITEM WARRANTY 5 Year
PRODUCT TYPE Multi Function Meter
SHAPE Square
ITME CONDITION New
PRODUCT WARRANTY 5 Year
NO. OF DAYS TO DISPATCH 3-4 Days
COUNTRY OF ORIGIN India
IS SALEABLE Yes

Applications
• Commercial and industrial sub-metering and energy management (EMS) applications.
• Building management and monitoring systems (BMS)
• High, medium and low-voltage switchgear panels
• Control and relay panels
• Power Control Centre (PCC) panels
• Motor Control Centre (MCC) panels
• Relaying and control outputs
• Plant automation and monitoring system (SCADA/DAS)
Benefits
• Easy interface with external devices through built-in Modbus (RS-485/Ethernet)
• Detachable connectors for easy installation
• Diagnostics assistance on display
• Suitable for star or delta connections and for low or high voltage applications
• Cost-effective online monitoring
• Field-configurable CT/PT primary and secondary values using push-buttons

Features
• Large four-line seven-digit display (9.7 H x 5 W mm) with
• quadrant identification section and bar graph for
• instantaneous power-level indication
• High accuracy: Class 0.2s, 0.5s, 1.0
• Average THD measurement for voltage, current and power, up to 31st harmonic
• Measurement selection (star or delta/ 3P4W or 3P3W)
• Modbus communication via RS-485 port/ethernet
• True root-mean squared (RMS) metering
• Calibration LED for accuracy test on site
• Wide and configurable current range 1-2A and 5-10A
• Wide-range auxiliary power supply, suitable for high-voltage or low-voltage installations
• Maximum demand recording
• Midnight snapshot (values) for selected energy registers
• Scroll-lock and ‘Favourites Page’ display support
• Expansion capability via add on modules for analogue
• outputs or pulse inputs/outputs and ethernet
• Password protection for setup mode
• Ethernet gateway module for easy integration of multiple meters connected over RS485 network

Weight 0.200 kg
