Indobazzar : Secure Elite 500 CL 0.5s upto 15th Harmonic – Multi Functional Meter
Secure Elite 500 CL 0.5s is a set of devices with advanced power monitoring capabilities. It can be used for standalone device monitoring and power quality analysis as a part of the building management system (BMS). It can also process industrial controls and SCADA systems. It offers data logging, the ability to control IOs, and modular communication with multiple protocols for third party system integration. Elite 500 allows customers to select either a conventional type of CT or Rogowski coil input, depending on the application. These can be directly connected to the meter without the need for any additional integer.
Common product for 1P2W / 3P3W / 3P4W applications, 35 V to 500 V (L-L) max, 20 V to 300 V (L-N) max, 10mA – 6 A (configurable), 5% Ipr -Ipr (Ipr -1000 A or 4000 A, 2 times of nominal voltage value for 1 Sec repeated 10 times at 10 second interval
ARRPVED STATE
All State Approved
ITEM WARRANTY
5 Year
PRODUCT TYPE
Multi Function Meter
SHAPE
Square
ITME CONDITION
New
PRODUCT WARRANTY
5 Year
NO. OF DAYS TO DISPATCH
3-4 Days
COUNTRY OF ORIGIN
India
IS SALEABLE
Yes
Application
Energy transfer measurement and reconciliation
Power plants, feeder monitoring, grid substations, wind turbines, renewables, industrial and commercial premises
Online monitoring of energy exchange at various interface points
Automation and system integration
Process and factory automation
Retrofit application up to 4000A can be served by using Rogowski coil
Different field add-on modules supporting different applications like Modbus, BACnet, Profinet, IEC 61850 protocol support, analogue output and control IOs
Various industries like oil and gas, mining, hospitals, malls, datacentres, etc.
LV, MV, and HV switchgear
Benefits
Minimal integration cost through hot-pluggable modular options for multiple communication ports
Support of multiple industry standard protocols: MODBUS RTU / TCP, Profinet, BACnet and IEC 61850 for integration with SCADA and other automation systems
Field-replaceable hot-pluggable communication, PIPO, alarm and analogue output modules
Supports energy efficiency measurement and LEED certification
Large, high-resolution, colour display for both analytical and graphical views
Options to have conventional CT or Rogowski coil
Features
TFT colour display showing vector diagram, bar chart, weekly /monthly energy consumption comparison
17 energy parameter measurement support including net and absolute energy parameters
Energy resolution: 7+3-digit, instantaneous parameters: 4+3-digit, high-resolution page for energy measurement
Class 0.2S / 0.5S accuracy for energy measurement
Configurable favourite parameter on the display page
Time synchronisation options through SNTP
Power quality features including individual harmonics, THD, sag, swell, voltage unbalance and interruption counter
Total demand distortion (TDD) factors and waveform quality indices like K factor and crest factor
